Introduction:
|
AD-DVI/A-04 Product Description: AD-DVI/A-04 is a DVI with the audio output signal card, belonging to the MHD series of matrix. It is provided with 4 DVI output interface, 4 audio output interface, the output enhancement, support for long distance transmission. The product parameters: Input card; The input signal is 4 DVI signals Input connector mother port db24+5/HDMI The input level of T.M.D.S.2.9V/3.3V The input impedance of 75 ohms Output card; The output signal of the 4 DVI signals Output connector mother port db24+5/HDMI Output level T.M.D.S.2.9V/3.3V The output impedance of 75 ohms Routine Gain 0dB Video signal 1 DVI1.0 standard DVI-D full digital T.M.D.S signals The switching rate of 200ns (max) The HDMI standard uses the HDMI1.3 standard EDID and DDC management support extended display identification (EDID) and display shujiu channel (DDC) using the DVI and HDMI standards HDPC management support high bandwidth digital content protection (HDCP) using DVI and HDMI1.3 standard Broadband 30MHz (10.2Gbit/s) The maximum time delay 5nS (+ 1nS) Crosstalk <-50dB@5MHz |
