Introduction:
|
Product description: - S3C2440 processor, running faster, more stable system - XC3S200A, FPGA, performance is more stable; Using high-speed digital switching technology, the perfect solution, ghosting and smearing crosstalk. 100% video effects of real return input signals; - 6.5GHz high bandwidth chip, the image is particularly clear; - support DVI1.0 protocol, the default use of EDID access technology; Support signal retiming, CEC, 36 bit color technology - plug-in design, support 4 or 8 single channel signal card - 18 channel signal card slot, a single card with a minimum of 4 36 way DVI digital signal input, 36 DVI digital signal output DVI-D 24+1 pure digital interface for input and output interface - one of the EDID automatic editing, read the fastest 50N seconds Digital synchronous recognition processing (DSIP) technology - with clock instructions, you can set the password lock - support seamless integration of CMMAW and CCSEB power management technology; - 3D new blue matrix display, full Chinese display working status Built in round robin function, can set the interval time and channel - 32 sets of memory functions, can be directly in the panel operation - supports DVI full digital T.M.D.S. signal in video type DVI1.0 specification; - support for accurate adaptive compensation, the maximum input distance to 38 meters - video signal input, output end using the full digital DVI-D interface; Support input signal condition monitoring, real-time monitoring and display of the current input channels are effective signal access Supports load access monitoring, real-time monitoring and display of the output channel is connected with load; Special port, can be directly and the wireless touch screen connection, plug and play; - the full patch SMD process, specific ESD electrostatic protection; - Universal wide voltage design, can adapt to the exchange of 100 ~ 240V, 50/60Hz; - high quality, mass production, with high compatibility and stability, has a high cost; Technical parameters: Product category: DVI matrix switcher - interface bandwidth: 6.5GHz (-3Db) full load - gain dB:0 - pixel bandwidth: 225 MHz full digital Clock jitter: Tbit <0.15 Rise time: <0.3Tbit (20%--80%) Decrease time: <0.3Tbit (20%--80%) - Protocol: DVI1.0 protocol, HDMI1.4, HDCP - switching speed: 200 ns (maximum time) - supported resolution: HDPC:, 1920x1200P@ 60_24bit Normal-PC:1600x1200@60_24bit, -:1920x1080P@60_36bit HDTV Interface:DVI-D master interface Signal strength: T.M.D.S + / - 0.4Vpp. - level information: 2.9V/3.3V T.M.D.S Impedance:50 - input EDID:50ns fast EDID edit Enter distance: less than 38 meters (line of sight) - output distance: less than 40 meters (line of sight) Control interface: RS-232, 9- pin mother D type interface - baud rate: baud rate: 9600, 8: data bits, stop bits: 1, no parity - serial structure: 2 = TX, 3 = RX, 5 = GND - keyboard control: matching the use of KEYBOARD and extended keyboard KT-B8W Control interface: 4 pin Phoenix - use: with the expansion of the keyboard KT-B8W supporting the use of Network controls: support for the TCP/IP protocol (optional) Control interface: RJ-45 master interface - power:100VAC ~ 50/60, Hz 240VAC, international adaptive power supply Temperature: storage, use of temperature: -20 ~ C ~ +70 Humidity: storage, use of humidity: 10% ~ 90% - Case Size: Standard 6U case - average failure: 60000 hours |
