- each output video with character overlap display function
Adopt (OPT) built-in IP control module and video server design, through the IP network to the host matrix
- operation and switching to browse the video image, remote and can control access to the camera and system
Adopt high density 16U plug-in module combination structure, convenient combination of expansion
Can be set to monitor keyboard, camera system can partition set permissions;
We have hot backup host selection and design, so that the host stability more secure
- audio / video input and output port and the communication interface with surge protection measures and anti lightning interference Design
- system can be carried out through the RS485 multiple multi-stage matrix network
A variety of networking functions can be external 16 control keyboard and can support more than three levels
With all - in English menu, can the functions of matrix are pre set
- alarm linkage, automatically open the camera and lighting, automatic switching preset point and start the video image
- can be preset any standoff alert mode: timing, manual, often cloth / Chefang and query alarm record
Input - built in 16 way alarm, 2 police output, you can cascade alarm interface unit alarm expansion.
- matrix system can be divided into free switch, program switching, synchronous switch, switch and an alarm switch group five system switching mode.
The parameters of the equipment:
Power supply < 80W AC220V + 10% / 50Hz
Video input 1Vp-p (75 Ohm load, unbalanced)
Video output 1Vp-p (75 Ohm load, unbalanced)
50dB video signal to noise ratio (weighted)
Video isolation 50dB (weighted)
Video bandwidth is 17MHz (-3db)
Differential phase typically 2%
The differential gain of the typical value is 2%
Video standard CCIR and PAL system
Audio input amplitude 0-2Vp-p
Audio output power of 0.5W (8W)
The audio signal to noise ratio of 48dB (weighted)
Audio isolation 48dB (weighted)
Audio bandwidth of 20KHz (-3db)
The switching time of 1 ms <
Audio video / audio interface: BNC socket socket: RCA
The environmental temperature of -10 DEG ~55 DEG
The environmental humidity is less than or equal to 90 percent of RH (condensation)
Dimension 483mm (L) * 430mm (W) * 712mm (H)
The weight of 50Kg (full module approximate weight
